- Vertical beaters.
- Vertical beaters feature “REVERSE FLIGHTING” on the top 21″ of the beater flighting. This patented feature allows for an even spread pattern of material.
- All Hydraulic Push models use solid virgin grade poly with UV inhibitor, for the floor and sides allowing less friction.
- The hydraulic endgate has 2 cylinders with ⅜″ hose and pipe for faster operation in cold weather.
- Heavy duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.
- The bottom drive Monoblock Gearbox features an overrunning clutch that provides protection to the driveline.
- The Hydraulic Push-Off System on all models features two hydraulic cylinders that sequence to reduce push-off forces for fast unloading of material.
- Beater blades are replaceable and the beater assembly is removable for stockpiling manure.
- Removal of the beater assembly is done by simply removing the mounting bolts and disconnecting the PTO gearbox driveshaft .
Auto Oiler
An Auto Oiler for the vertical beater drive chains is standard equipment.
An Auto Oiler for the vertical beater drive chains is standard equipment.
Heavy Duty Frame
Heavy duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.
Heavy duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.
Vertical Beaters
The 4142 & 4155 can be ordered with a vertical beater assembly or horizontal beater. Beater assemblies are interchangeable.
The 4142 & 4155 can be ordered with a vertical beater assembly or horizontal beater. Vertical beaters feature “REVERSE FLIGHTING” on the top 21″ of the beater flighting. This patented feature allows for an even spread pattern of material. Beater assemblies are interchangeable. Removal and installation of either beater assembly is done by removing the mounting bolts and a drive chain, interchanging beaters, then reinstalling the mounting bolts and drive chain. Beater gearboxes are safely mounted on the top side of the vertical beaters rather than the bottom to avoid being destroyed by foreign objects.
Center Drive System
The HP’s PTO beater drive system consists of a straight shaft off the PTO underneath the center of the manure spreader to an angle gearbox in the rear, and over to the beater drive sprocket.
The HP’s PTO beater drive system consists of a straight shaft off the PTO underneath the center of the manure spreader to an angle gearbox in the rear, and over to the beater drive sprocket.
Reduce Push Off Forces
The H&S Hydraulic Push-Off System on all models feature a hydraulic variable speed control and two hydraulic cylinders that sequence to reduce push-off forces and fast unloading of material.
The H&S Hydraulic Push-Off System on all models feature a hydraulic variable speed control and two hydraulic cylinders that sequence to reduce push-off forces and fast unloading of material.
Clean Out Pan
The vertical beater features a quick release clean out pan.
The vertical beater features a quick release clean out pan. The left photo shows the pan in the open position for clean out, and the right photo shows the pan in the closed position for operation.
Solid Virgin Grade Poly Liner
All Hydraulic Push models use solid virgin grade poly with UV inhibitor, for the floor and sides allowing less friction.
All Hydraulic Push models use solid virgin grade poly with UV inhibitor, for the floor and sides allowing less friction. The hydraulic endgate has 2 cylinders with 3/8' hose and pipe for faster operation in cold weather.
| HPV4142 |
| CAPACITY – OLD RATING |
425 Bushel |
| CAPACITY CU. FT, STRUCK LEVEL |
270 |
| SIDE LOADING HEIGHT |
61 ¼″ |
| 2ND OR VERTICAL BEATER HEIGHT |
104 ½″ |
| HEIGHT-TOP OF HYD. END GATE (W/O HOOK) |
65″ |
| HEIGHT-TOP OF SCREEN (VERT. BEATER ONLY) |
98″ |
| INSIDE WIDTH |
72″ |
| INSIDE LENGTH |
16′ |
| INSIDE DEPTH |
34″ |
| OVERALL WIDTH W/TIRES |
10′ 2″ |
| OVERALL LENGTH |
27′ 5″ |
| STANDARD NUMBER OF BEATERS |
2 |
| HORIZONTAL BEATER DIAMETER/LOWER |
N/A |
| HORIZONTAL BEATER DIAMETER/UPPER |
N/A |
| VERTICAL BEATER DIAMETER |
34″ |
| REPLACEABLE BEATER PADDLES |
YES |
| REMOVEABLE BEATER ASSEMBLY |
YES |
| HYDRAULIC PUSH CYLINDER DIAMETER |
3 ½″ |
| HYDRAULIC PUSH CYLINDER HOSE DIAMETER |
⅜″ |
| HUB |
8 Bolt |
| SPINDLE SIZE |
3″ |
| TIRE SIZE – STANDARD |
425 x 22.5 |
| TIRE SIZE – OPTIONAL |
19L x 16.1 10 Ply |
| HYDRAULIC END GATE |
Standard |
| CYLINDERS ON HYDRAULIC END GATE |
2 W-⅜″ Hose |
| REAR PAN |
Standard |
| JACK |
Standard |
| WOOD SIDE RAILS |
Standard |
| WEIGHT W/TIRES |
7,900# |
| PTO CHOICES |
1,000 PRM PTO
1¾ or 1¾ w/ SHEAR BOLT PROTECTION |
YES |
1,000 PRM PTO
1¾ or 1¾ w/ OVER RUNNING TORQUE LIMITING CLUTCH |
YES |
WARRANTY: SEE OERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
