HPV4255 Manure Spreader Information

  • Vertical beaters
  • Vertical beaters feature REVERSE FLIGHTING on the top 21″ of the beater flighting. This patented feature allows for an even spread pattern of material.
  • All Hydraulic Push models use solid virgin grade poly with UV inhibitor for the floor and sides, allowing less friction.
  • The hydraulic endgate has 2 cylinders with ⅜″ hose and pipe for faster operation in cold weather.
  • Heavy-duty rectangular tubing is used for the pole to ensure strength and long life. Structural channel floor supports spaced 9 ½″ apart are used for maximum floor support.
  • The bottom drive monobloc gearbox features an overrunning clutch that provides protection to the driveline.
  • The hydraulic push-off system on all models features two hydraulic cylinders that sequence to reduce push-off forces for fast unloading of material.
  • Beater blades are replaceable, and the beater assembly is removable for stockpiling manure.
  • Removal of the beater assembly is done by simply removing the mounting bolts and disconnecting the PTO gearbox driveshaft.
HPV4255
CAPACITY – HEAPED (OLD RATING) 550 Bushel
CAPACITY CU. FT. STRUCK LEVEL PER ASAE S324.2 383.39
CAPACITY CU. FT. HEAPED PER ASAE S324.2 511.27
SIDE LOADING HEIGHT PER ASAE S324.2 81″
VERTICAL BEATER HEIGHT 121 ½″
HEIGHT-TOP OF HYD. END GATE (W/O HOOK) 85 ½″
HEIGHT-TOP OF SCREEN (VERT. BEATER ONLY) 117″
INSIDE WIDTH 72″
INSIDE LENGTH 15′
INSIDE DEPTH 53″
OVERALL WIDTH W/TIRES 10′ 2″
OVERALL LENGTH 29′ 1″
STANDARD NUMBER OF BEATERS 2
VERTICAL BEATER DIAMETER 34″
REPLACEABLE BEATER PADDLES YES
REMOVEABLE BEATER ASSEMBLY YES
HYDRAULIC PUSH CYLINDER DIAMETER 4 ½″
HUB 10 Bolt
SPINDLE SIZE 3″
HITCH CHOICES Clevis or Bullnose
TIRE SIZE – STANDARD USED
TRUCK TIRES,
OR HEAVY-DUTY
TANDEM AXLE
W/600/50 X 22.5
HYDRAULIC ENDGATE Standard
CYLINDERS ON HYDRAULIC ENDGATE 2 W-⅜″ Hose
JACK Standard
POLY SIDE RAILS Standard
WEIGHT W/TIRES 11,000#
PTO CHOICES
1-3/8 1,000 PRM PTO W/OVERRUNNING CLUTCH
YES
1-3/4 1,000 PRM PTO W/OVERRUNNING CLUTCH YES

WARRANTY: SEE OPERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
