Single Axle Running Gear

  • Spring Assist Pole
  • Adjustable Wheel Base
  • Greasable Automotive Style Ball Joints
  • Retractable Automatic Re-lock Tongue Latch
  • Tapered Roller Bearings in Main Pivot Points
  • Safety Chain
  • Full Contact Turn Stops distributes the pressure exerted in tight dragging turns along the bolster face – this reduces the possibility of bunk damage or collapse.
  • 1620 Running Gear has a 4-bolt brake flanges as standard equipment so that optional 2-wheel hydraulic disc brakes may be installed.
410
CAPACITY 20,000#
WEIGHT W/O RIMS & TIRES   740#
TREAD WIDTH 80″
SPINDLES 2″
HUBS 6 Bolt
BOLSTER 3″ x 6″ x 1/4″
REACH 3” O.D. x .188 Wall – Round Tube
WHEEL BASE
TIRE & RIM OPTIONS 15 x 10
WHEEL OPTIONS N/A
BRAKES N/A
BACK HITCH YES
TELESCOPING POLE Retractable Automatic Relock
412
CAPACITY 12 TON
WEIGHT W/TIRES 1190# w/12.5L
TREAD WIDTH 80″
SPINDLES 2.25″
HUBS 8 BOLT
BOLSTER 3″ x 8″
C-REACH 7 GAUGE
WHEEL BASE 119″ TO 159″ IN 10″ INCREMENTS
STANDARD WHEEL 15 x 10
WHEEL OPTIONS 16.1 x 11 22.5 x 8 22.5 x 13.5
BRAKES OPT. HYD. SURGE
BACK HITCH YES
TELESCOPING POLE 77″ FIXED, EXTENDS TO 89″
415
CAPACITY 15 TON
WEIGHT W/TIRES 1520# w/16.5L
TREAD WIDTH 80″
SPINDLES 2.75″
HUBS 8 BOLT
BOLSTER 4″ x 8″
C-REACH ⅜″ WELDMENT
WHEEL BASE 119″ TO 179″ IN 10″ INCREMENTS
STANDARD WHEEL 16.1 x 14
WHEEL OPTIONS 22.5 x 8 22.5 x 13.5
BRAKES OPT. HYD. SURGE
BACK HITCH YES
TELESCOPING POLE FIXED AT 89″
417
CAPACITY 17 TON
WEIGHT W/TIRES 2100# w/19L
TREAD WIDTH 87″
SPINDLES 3″
HUBS 8 BOLT
BOLSTER 4″ x 8″
C-REACH ⅜″ WELDMENT
WHEEL BASE 119″ TO 179″ IN 10″ INCREMENTS
STANDARD WHEEL 16.1 x 16
WHEEL OPTIONS 16.1 x 14 22.5 x 8 22.5 x 13.5
BRAKES OPT. HYD. SURGE
BACK HITCH YES
TELESCOPING POLE FIXED AT 89″

WARRANTY: SEE OERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
