ALL MODELS EXCEPT THE 5215 are available with the optional Digi-Star GT400, or Nutrient Tracker Scale System with GPS!
The heavy-duty expeller system with a quick release poly-lined fine spread pan, and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
- 40″ Wide “Top Shot” Expeller Beater
- 24″ Diameter Round Core Segmented Auger
- Left Side Poly Lined Tank
- Front and Rear Splash Guards
- Flip-Over Adjustable Hitch
- Overrunning Clutch /Torque Limiting Clutch & Shear Bolt Protection
- Shear Bolt Protection
- The auger System hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
- Automatic Chain Oiler System
- Highway Lighting System
- Remote Grease System
Adjustable Hitch
The 5226 manure spreader has a flip-over adjustable hitch for proper height adjustment.
The 5226 manure spreader has a flip-over adjustable hitch for proper height adjustment.
Expeller
The heavy-duty expeller system with a quick release poly-lined fine spread pan and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
The heavy-duty expeller system with a quick release poly-lined fine spread pan and side fins help cut the drift of material towards the tractor and spreader, and provide an excellent spread pattern.
Oiler System
An automatic oiler system oils the drive system chains anytime the discharge door is raised. A scraper holder is standard equipment.
An automatic oiler system oils the drive system chains anytime the discharge door is raised. A scraper holder is standard equipment. Jack storage is on the left side of the manure spreader.
Cylinder System
A master/slave cylinder system raises and lowers the main auger evenly to keep material moving to the expeller.
A master/slave cylinder system raises and lowers the main auger evenly to keep material moving to the expeller.
Lighting System
The highway lighting system connects to the 7-pin tractor plug for added safety.
The highway lighting system connects to the 7-pin tractor plug for added safety.
Overrunning Clutch
The 5226 has an Overrunning Clutch /Torque Limiting Clutch and shear bolt protection for smooth power transfer.
The 5226 has an Overrunning Clutch /Torque Limiting Clutch and shear bolt protection for smooth power transfer.
Drive System
The 5226 drive system features a sprocket reduction system with heavy-duty chain.
The 5226 drive system features a sprocket reduction system with heavy-duty chain.
Manual Adjust
The manual adjust top expeller shield sets the distance of the spread pattern, while the hydraulic cylinder allows adjustment for rate of application.
The manual adjust top expeller shield sets the distance of the spread pattern, while the hydraulic cylinder allows adjustment for rate of application. Reversible bolt-on square tooth paddles shred and rip material with a “Top Shot” action for an even spread pattern.
Segmented Auger
The left side poly liner allows material to slide to the auger. The 5226 features a 24″ diameter round core segmented auger.
The left side poly liner allows material to slide to the auger. The 5220 features a 24″ diameter round core segmented auger. All Auger Systems hydraulically raise and lower a full 8″ to break-up material that may bridge during the unloading process.
| 5220 |
| CUBIC FT. STRUCK LEVEL |
268.6 |
| GALLON CAPACITY |
2009 |
| TANK LENGTH |
16′ |
| OVERALL LENGTH |
22′ 8″ |
| TANK WIDTH – TOP |
76″ |
| AUGER DIAMETER |
24″ |
| POLY LINED TANK |
Left Side |
| OVERRUNNING CLUTCH |
Yes |
| SHEAR BOLT PROTECTION |
Yes |
| PTO |
540 RPM Std. 1000 RPM Opt. |
| EXPELLER WIDTH |
40″ |
| FRONT SPLASHGUARDS |
Standard |
| REAR SPLASHGUARDS |
Standard |
| AUTOMATIC OILER |
Standard |
| HIGHWAY LIGHTING |
Standard |
| WEIGHT |
6,860# |
| 5226 |
| CUBIC FT. STRUCK LEVEL |
347 |
| GALLON CAPACITY |
2596 |
| TANK LENGTH |
16′ |
| OVERALL LENGTH |
22′ 8″ |
| TANK WIDTH – TOP |
87″ |
| AUGER DIAMETER |
24″ |
| POLY LINED TANK |
Left Side |
| OVERRUNNING CLUTCH |
Yes |
| SHEAR BOLT PROTECTION |
Yes |
| PTO |
1000 RPM Std. 540 RPM Opt. |
| EXPELLER WIDTH |
40″ |
| FRONT SPLASHGUARDS |
Standard |
| REAR SPLASHGUARDS |
Standard |
| AUTOMATIC OILER |
Standard |
| HIGHWAY LIGHTING |
Standard |
| WEIGHT |
7,880# |
| 5234 |
| CUBIC FT. STRUCK LEVEL |
451 |
| GALLON CAPACITY |
3377 |
| TANK LENGTH |
16′ |
| OVERALL LENGTH |
23′ 7″ |
| TANK WIDTH – TOP |
97″ |
| AUGER DIAMETER |
30″ |
| POLY LINED TANK |
Left Side |
| OVERRUNNING CLUTCH |
Yes |
| SHEAR BOLT PROTECTION |
Yes |
| PTO |
1 ⅜″ or 1 ¾″ 1000 RPM |
| EXPELLER WIDTH |
40″ |
| FRONT SPLASHGUARDS |
Standard |
| REAR SPLASHGUARDS |
Standard |
| AUTOMATIC OILER |
Standard |
| HIGHWAY LIGHTING |
Standard |
| WEIGHT |
10,940# |
| 5226 TIRE SPECIFICATIONS |
| w/16.1 X 16.5 Tires |
|
| SIDE LOADING HEIGHT |
81″ |
| HEIGHT @ REAR CYL. BRACKET |
N/A |
| HEIGHT @ FRONT SPLASH |
88″ |
| HEIGHT @ REAR SPLASH |
82″ |
| OVERALL WIDTH |
103″ |
| w/425 X 22.5 Tires |
|
| SIDE LOADING HEIGHT |
83″ |
| HEIGHT @ REAR CYL. BRACKET |
N/A |
| HEIGHT @ FRONT SPLASH |
90″ |
| HEIGHT @ REAR SPLASH |
84″ |
| OVERALL WIDTH |
102″ |
| w/19L X 16.1 Tires |
|
| SIDE LOADING HEIGHT |
84″ |
| HEIGHT @ REAR CYL. BRACKET |
N/A |
| HEIGHT @ FRONT SPLASH |
91″ |
| HEIGHT @ REAR SPLASH |
85″ |
| OVERALL WIDTH |
105″ |
WARRANTY: SEE OERATORS MANUAL FOR WARRANTY DETAILS AND LIMITATIONS. H&S RESERVES THE RIGHT TO CHANGE ITS PRODUCTS OR THE DESCRIPTION AT ANY TIME WITHOUT NOTICE OR OBLIGATION. MODELS AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
